Diesel Motor
Kohler LDW 1003 3cyl.
Kohler LDW 1404 4cyl.
Kubota D1105 3cyl.
Kubota V1505 4cyl.

Traction
Hydrostatic on 2 or 4 wheels.
On request: hydraulic motor with variable cylinder capacity electrically controlled.

Gears
2 gears + neutral in central position - electrical control from control panel.

Steering
Whit hydraulic power steering on the front wheels.
Indipendent steering on the rear wheels (only 4 wd).
With 3 positions selector indipendent and/or combined on request.

Speed
min 0 km/h max 13 km/h

Brakes
Nr. 4 hydraulic platforms. Parking/negative brake on 4 wheels. On request hydraulic brakes on 4 wheels.

Fruit collector
One central collector with idraulic lift (available size and vertical lift rails can be seen in the diagrams shown below). Detachable footguard.

Front lift (on request)
Hydraulic lift for second choice bins up to 500 kg capacity.

Rear lift
Hydraulic lift for unloading and bins filling up to 500 kg capacity.

Harvesting belts
Nr. 6 harvesting belts (2 for harvesting from the ground + 4 at the service of the platforms).

Pruning system
C.500/C.600 lt compressor - electromagnetic coupling, control on panel.

Total capacity of the machine: 13,200 lbs.
